Konica Minolta KM1024i LHE 30PL printhead

$871.00

Reference:

The Konica Minolta KM1024i LHE 30PL printhead is high speed, high productivity with ‘independent’ firing technology – not limited by the low speeds of older ‘shared wall’ technology.
SKU: PPHKM19089
Quantity

Description

The Konica Minolta KM1024i LHE 30PL printhead is high speed, high productivity with ‘independent’ firing technology – not limited by the low speeds of older ‘shared wall’ technology. Proven in a wide range of single-pass systems, providing print up to 80 meters per minute from a single row of heads. The KM1024i printhead is available in 6, 14 and 30pl drop sizes. This Konica Minolta KM1024i LHE 30PL printhead is the large native drop volume variant (30pl) for UV inks (integrated heater).

Specifications
- Technology: Piezo Drop On-Demand
- Grey scale: 8 levels

- Native Resolution: 360 dpi (4 rows x 90 dpi)
- Native drop volume (L): 30 pl
- Max. Drops in Greyscale: 8 drops
- Tot. Amount of Nozzles: 1024 (256 x 4 rows)
- Print Width: 72.12 mm
- Max Firing Frequency: 27 kHz
- Drive Voltage: 13+-3V
- Ink Compatibility: UV
- Heater: integrated
- Recommended temperature: under 55 degrees C
- Dimensions: W131mm x D18mm x H94mm
- Weight: less than 150g

Printer compatibility

Agfa Anapurna 100
Agfa Anapurna H2500i LED
Agfa Anapurna M2050i
Agfa Anapurna M2500i
Agfa Anapurna M2540 FB
Agfa Anapurna M3200i

Allwin S320UV
Allwin S500UV
Allwin UVT 2030
Allwin UVT 2512
Allwin UVT+ 2030
Allwin UVT+ 2512

Docan H1000

Flora HJ 5000UV

Human Digital Technology M-JET

IIJ ColourPrint-72

JHF Vista R3300
JHF Vista R6000
JHF Vista V300UV
JHF Vista V500UV

Optimum Digital KR Hybrid UV

Skyjet FT2512i
Skyjet FT3020i

Taimes T50UV

Yicong YD2512-KD
11 Items
